●2RT 前頂油缸行程300mm, 增加使用者上下料的作業空間。
●上下隔熱板采用玻纖板，導熱系數0.1W/m.k, 隔熱效果佳。
●出入模板向外滑模處，滑軌導座上安裝耐磨銅導軌，出入模運行平順。
●輔助油缸，真空罩油缸，非運動部位油管采鋼管配置，整體機臺配管配線整齊。
● Wear resistant copper guide rail shall be installed on the guide seat of the slide rail at the
external sliding formwork of the entrance and exit formwork,and the operation of the entrance
and exit formworkshall be smooth.
● The auxiliary oil cylinder,vacuum hood oil cylinder,and oil pipes at non moving parts shall be
configured with steel pipes,and the overall machine table piping and wiring shall be neat.
技術參數
Technical Parameter
Mode | 單位 | 100 Ton | 150 Ton | 200 Ton | 250 Tor | 300 Ton | 350 Ton | 400 T0I | 500.10 |
出力 Output | Ton | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 500 |
行程 Inp | 200 | 250 | 250 | 250 | 300 | 300 | 300 | 350 | |
合面 Mes | mm | 385*400 | 445*460 | 535*560 | 620*600 | 620*650 | 700*700 | 775*800 | 825*850 |
熱板厚度Hot plate thickness | 1m | 62 | 62 | 68 | 72 | 72 | 82 | 82 | 82 |
工徑 Cylinder bore | mm | 255 | 310 | 355 | 400 | 450 | 475 | 500 | 560 |
馬力/伺服Horsepower/Servo | kw | 5.5*2 | 5.5*2 | 7.5*2 | 7.5*2 | 9*2 | 11*2 | 11*2 | 11*2 |
開模方式Mold opening mode | 上升/下降-出入模-RT/軌道開模 | ||||||||
雙軸電熱Doube axis electric heatiy | kw | 13.2 | 18 | 28.8 | 40.8 | 43.2 | 60 | 64.8 | 74.4 |
電力 Total electriaty | KW | 24.2 | 29 | 43.8 | 55.5 | 61.2 | 82 | 86.8 | 96.4 |
